在機械傳動領域，絲杠如同設備運行的 “合理標尺”，但軸向間隙的存在卻會讓這份合理大打折扣，導致設備運行出現位移偏差、振動加劇等問題。想要讓絲杠恢復穩定快捷的傳動性能，消除軸向間隙勢在必行，這需要從原理分析到方法應用，步步為營攻克難題。

　　In the field of mechanical transmission, the screw is like a "precise ruler" for equipment operation, but the existence of axial clearance can greatly reduce this accuracy, leading to displacement deviation, increased vibration and other problems during equipment operation. It is imperative to eliminate axial clearance in order to restore stable and efficient transmission performance of the screw. This requires a step-by-step approach from principle analysis to method application to overcome difficulties.

　　找準 “病根”：解析間隙產生的源頭

　　Identifying the 'root cause': Analyzing the source of gap generation

　　絲杠產生軸向間隙的原因多種多樣。長期使用后，絲杠與螺母的螺紋面磨損，配合精度下降，會導致間隙逐漸提升；裝配過程中，如果安裝不當，比如絲杠與支撐軸承的同軸度誤差過大，或者螺母與工作臺的連接不牢固，也會造成軸向間隙出現。此外，溫度變化引起的熱脹冷縮，以及設備運行時受到的沖擊載荷，都會使絲杠的軸向位置發生微小變動，久而久之形成間隙。只有明確間隙產生的具體原因，才能 “對癥下藥” 選擇合適的消除方法。

　　There are various reasons for the axial clearance of lead screws. After long-term use, the threaded surface of the screw and nut will wear out, the fitting accuracy will decrease, and the gap will gradually increase; During the assembly process, improper installation, such as excessive coaxiality error between the lead screw and the supporting bearing, or loose connection between the nut and the worktable, can also cause axial clearance. In addition, thermal expansion and contraction caused by temperature changes, as well as impact loads experienced during equipment operation, can cause slight changes in the axial position of the screw, leading to the formation of gaps over time. Only by identifying the specific reasons for the gap can appropriate elimination methods be chosen accordingly.

　　墊片調整法：“加減” 之間的合理調控

　　Gasket adjustment method: precise control between "addition and subtraction"

　　墊片調整法是較為常見且基礎的消除方式。在絲杠的軸承座與安裝基面之間，通過增減墊片的厚度來調整軸向位置。先拆卸絲杠的軸承端蓋，測量現有間隙大小，根據測量結果選擇合適厚度的墊片。若間隙較小，可增加較薄的墊片；間隙較大時，則需更換較厚的墊片。添加墊片后，重新安裝軸承端蓋并擰緊螺栓，此時通過墊片的厚度補償，絲杠與螺母的軸向配合得到調整，間隙得以減小。這種方法操作相對簡單，但對墊片厚度的選擇要求較高，需要多次嘗試和測量，以達到非常佳的間隙消除效果。

　　The gasket adjustment method is a common and fundamental elimination method. Adjust the axial position between the bearing seat of the screw and the installation base by increasing or decreasing the thickness of the gasket. First, remove the bearing end cover of the screw, measure the existing gap size, and select the appropriate thickness gasket based on the measurement results. If the gap is small, thinner gaskets can be added; When the gap is large, a thicker gasket needs to be replaced. After adding the gasket, reinstall the bearing end cover and tighten the bolts. At this time, the axial fit between the screw and nut is adjusted by compensating for the thickness of the gasket, and the gap is reduced. This method is relatively simple to operate, but requires high selection of gasket thickness, requiring multiple attempts and measurements to achieve the best clearance elimination effect.

　　雙螺母預緊法：“雙向擠壓” 的穩定之道

　　Double nut pre tightening method: the stable way of "bi-directional extrusion"

　　雙螺母預緊法能有效提高絲杠的傳動精度和剛性。在同一根絲杠上安裝兩個螺母，通過一定方式使兩個螺母產生軸向相對位移，形成預緊力，從而消除間隙。常見的預緊方式有墊片預緊、螺紋預緊和齒差預緊。墊片預緊是在兩個螺母之間安裝墊片，通過調整墊片厚度使螺母產生相對位移；螺紋預緊則是利用螺母上的螺紋結構，旋轉其中一個螺母改變兩者間距；齒差預緊是在兩個螺母的凸緣上加工出齒數不同的齒輪，與固定在螺母座上的內齒圈相嚙合，通過調整齒輪的相對位置實現預緊。雙螺母預緊后，無論絲杠受到哪個方向的軸向力，大多能通過兩個螺母的相互擠壓抵消間隙，使傳動更加平穩、合理。

　　The double nut pre tightening method can effectively improve the transmission accuracy and rigidity of the screw. Install two nuts on the same lead screw, and use a certain method to cause axial relative displacement between the two nuts, forming a preload force to eliminate the gap. Common pre tightening methods include gasket pre tightening, thread pre tightening, and tooth difference pre tightening. Pre tightening of gaskets is the process of installing gaskets between two nuts and adjusting the thickness of the gaskets to cause relative displacement of the nuts; Thread pre tightening is the use of the thread structure on the nut, rotating one of the nuts to change the distance between the two; Tooth difference pre tightening is the process of machining gears with different numbers of teeth on the flanges of two nuts, meshing with the internal gear ring fixed on the nut seat, and achieving pre tightening by adjusting the relative position of the gears. After pre tightening the double nuts, regardless of the direction of axial force on the screw, the clearance can be offset by the mutual compression of the two nuts, making the transmission smoother and more accurate.

　　更換磨損部件：“除舊布新” 的有效修復

　　Replacing worn parts: a thorough repair of "removing old and replacing with new"

　　當絲杠或螺母磨損嚴重，其他方法難以達到理想效果時，更換磨損部件是非常直接有效的措施。先拆卸絲杠和螺母，仔細檢查其磨損情況，確認需要更換后，選擇與原型號規格一致的新品。安裝新部件時，嚴格按照裝配工藝要求操作，確保絲杠與螺母的同軸度、平行度等參數符合標準。同時，對相關的軸承、密封件等也進行檢查和更換，避免因其他部件的問題再次引發軸向間隙。更換完成后，還需進行多維度的調試和檢測，確保絲杠的傳動性能恢復正常。

　　When the screw or nut is severely worn and other methods are difficult to achieve the desired effect, replacing the worn parts is the most direct and effective measure. First, disassemble the lead screw and nut, carefully inspect their wear condition, confirm that they need to be replaced, and then select a new product that is consistent with the original model specifications. When installing new components, strictly follow the assembly process requirements to ensure that the coaxiality, parallelism, and other parameters of the screw and nut meet the standards. At the same time, relevant bearings, seals, etc. are also inspected and replaced to avoid further axial clearance caused by problems with other components. After the replacement is completed, comprehensive debugging and testing are needed to ensure that the transmission performance of the screw is restored to normal.

　　日常維護：間隙防控的 “長效機制”

　　Daily maintenance: a 'long-term mechanism' for gap prevention and control

　　消除軸向間隙后，日常維護同樣關鍵。定期對絲杠進行潤滑保養，使用合適的潤滑油或潤滑脂，減少螺紋面的摩擦和磨損；避免設備超負荷運行，防止過大的沖擊載荷對絲杠造成損傷；在設備停機期間，做好防塵、防潮措施，防止灰塵、水分進入絲杠與螺母的配合間隙，影響傳動精度。通過這些維護措施，能夠有效延緩絲杠軸向間隙的產生，延長設備的使用壽命。

　　After eliminating the axial clearance, daily maintenance is equally crucial. Regularly lubricate and maintain the screw, using appropriate lubricating oil or grease to reduce friction and wear on the threaded surface; Avoid overloading the equipment and prevent excessive impact loads from damaging the screw; During equipment shutdown, take measures to prevent dust and moisture from entering the clearance between the screw and nut, which may affect transmission accuracy. Through these maintenance measures, the generation of axial clearance of the screw can be effectively delayed, and the service life of the equipment can be extended.

　　絲杠軸向間隙的消除是保障機械傳動精度的重要環節。從剖析間隙根源到靈活運用各種消除方法，再到建立完善的維護機制，每一步都關乎設備的穩定運行。打贏這場 “清零行動”，才能讓絲杠在精密傳動的舞臺上持續發揮關鍵作用，為機械設備的快捷運轉保駕護航。

　　The elimination of axial clearance of screw is an important link to ensure the accuracy of mechanical transmission. From analyzing the root cause of gaps to flexibly applying various elimination methods, and then establishing a comprehensive maintenance mechanism, every step is related to the stable operation of the equipment. Winning this' zero tolerance action 'is essential for the screw to continue playing a crucial role on the stage of precision transmission, safeguarding the efficient operation of mechanical equipment.
